Conguring SATA Hard Drive(s)

Chapter3 ConguringSATAHardDrive(s)

(Note1) SkipthisstepifyoudonotwanttocreateRAIDarrayontheSATAcontroller.

(Note2) RequiredwhentheSATAcontrollerissettoAHCIorRAIDmode.

RAID 0 RAID 1 RAID 5 RAID 10

Minimum

NumberofHard

Drives

≥2 2 ≥3 ≥4

Array Capacity Numberofhard

drives*Sizeofthe

smallest drive

Sizeofthesmallest

drive

(Numberofhard

drives-1)*Sizeof

the smallest drive

(Numberofhard

drives/2)*Sizeofthe

smallest drive

Fault Tolerance No Yes Yes Yes

RAID Levels

TocongureSATAharddrive(s),followthestepsbelow:

A. InstallSATAharddrive(s)inyourcomputer.

B. CongureSATAcontrollermodeinBIOSSetup.

C. CongureaRAIDarrayinRAIDBIOS

(Note1)

D. Install the SATA RAID/AHCI driver and operating system

(Note2)

Before you begin

• AtleasttwoSATAharddrives(toensureoptimalperformance,itisrecommendedthatyouusetwoharddrives

withidenticalmodelandcapacity).IfyoudonotwanttocreateRAID,youmayprepareonlyoneharddrive.

• Windowssetupdisk.

• Motherboard driver disk.

• AUSBashdrive.

3-1 ConguringSATAControllers

A.InstallingSATAharddrive(s)inyourcomputer

Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available SATA

port on the motherboard. Then connect the power connector from your power supply to the hard drive.
