Gigabyte G1.Sniper Z6 [21/80] 7 changing the operational amplifier

- 21 -

Hardware Installation

1-7 ChangingtheOperationalAmplier

For purchasing the IC extractor and OP Chip, please contact the local dealer.

Step 1:

Use an IC extractor to carefully grip the IC's sides and extract it

from the socket.

Step 2:

Align the notch on your OP chip with the notch on the socket and

gently press the chip into the socket until seated.
