- 27 -
Hardware Installation
9) GAIN(AudioGainControlSwitches)
This switch allows for audio gain control for the line-out jack on the back panel. Please make sure all of
thedipsaresetinthesamepositionandaresetaccordingtoyourheadphonespecication(actualeffects
mayvarybythedevicebeingused).
F_USB30
F_U
B_
F_ F_
_
B
BS_
B
SB_
B
_S
S_
_
B
_U
_
B
S
123
123
123
123
1
1
1
1
BSS
S
_S
SSU
1 2 3
S3
BSSS
U
__ 3
F_USB3F
S _
S _
S _
SF
10) COMA(SerialPortHeader)
The COM header can provide one serial port via an optional COM port cable. For purchasing the optional
COM port cable, please contact the local dealer.
PinNo. Denition
1 NDCD-
2 NSIN
3 NSOUT
4 NDTR-
5 GND
6 NDSR-
7 NRTS-
8 NCTS-
9 NRI-
10 NoPin
10
9
2
1
Gain Ratio
DIP Setting
DIP 1 DIP 2 DIP 3 DIP 4
2.5x
OFF OFF OFF OFF
6x
ON ON ON ON
