STRIX H270F GAMING specifications summary
ASUS Special
Features
Gamers Guardian
- SafeSlot
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports
- Highly Durable Components
- Stainless Steel Back I/O
ASUS EZ DIY
- ASUS EZ Flash 3
- ASUS CrashFree BIOS 3
ASUS Q-Design
- Q-Shield
- Q-LED (CPU, DRAM, VGA, Boot Device LED)
- Q-Slot
- Q-DIMM
ASUS Exclusive Features
- AURA Lightning Control
- 3D Printing Friendly Design
- AI Charger
Internal I/O
connectors
2 x USB 3.0 connectors support additional 4 x USB 3.0 ports
2 x USB 2.0 connectors support additional 4 x USB 2.0 ports [one connector
via ROG_EXT header]
6 x SATA 6.0 Gb/s connectors (gray)
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 2 mode)
- 1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280/22110 storage
devices support ( Support PCIE mode only)
1 x 4-Pin AIO_PUMP fan connector
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
2 x 4-Pin Chassis fan connectors
1 x 5-Pin Extension fan connector
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x Front panel audio connector (AAFP)
1 x COM connector
1 x RGB Header
1 x TPM connector
1 x System panel connector
1 x Clear CMOS jumper (2-pin)
1 x Thermal sensor connectors
(continued on the next page)
