ix
STRIX H270F GAMING specifications summary
Storage
Intel
®
H270 Chipset
- 6 x SATA 6Gb/s ports*
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 2 mode)
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280/22110 storage
devices support (PCIE 3.0 x 4 mode), supports Intel
®
Optane Memory**
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Recovery
Technology
- Support Raid 0, 1, 5, 10
* When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port
cannot be used.
** These functions will work depending on the CPU installed.
Audio
SupremeFX 8-Channel High Definition Audio CODEC
- SupremeFX Shielding Technology
- Dual Headpone Ampliers
- Jack-detection, Multi-streaming, Multi-recording, and Front Panel Jack-
retasking
- Optical S/PDIF out port at back panel
Audio Features
- Sonic Radar III
- Sonic Studio III
USB
ASMedia USB 3.1 controllers - supports ASUS USB 3.1 Boost
- 2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C ports at back panel)
Intel
®
H270 Chipset
- 6 x USB 3.0/2.0 ports (4 ports @mid-board; 2 ports @back panel, blue,
Type A)
- 8 x USB 2.0/1.1 ports (4 ports @mid-board; 4 ports @back panel)*
* 2 x USB2.0 port at mid-board shares with ROG extension (ROG_EXT) port.
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst Technology
ROG Exclusive
Features
ROG RAMCache II
ROG GameFirst IV
ROG Overwolf
ROG CPU-Z
ROG Clonedrive
ASUS Special
Features
Performance Optimization
- DIGI + VRM
- GPU Boost
- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
- AI Suite 3
(continued on the next page)
