Asus ROG STRIX H270F GAMING [19/113] Chapter 1

ASUS STRIX H270F GAMING

1-5

Chapter 1

Recommended memory configurations

1.1.4 System memory

ThemotherboardcomeswithfourDDR4(DoubleDataRate4)QuadInlineMemoryModules

(DIMM)slots.

ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT

installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.

strix H270F GAMING

STRIX H270F GAMING 288-pin DDR4 DIMM sockets

DIMM_A1

DIMM_A2

DIMM_B1

DIMM_B2
