Asus ROG STRIX H270F GAMING [13/113] The tools and components listed above are not included in the motherboard package

xiii

Installation tools and components

The tools and components listed above are not included in the motherboard package.

PC chassis

Power supply unit

Intel

1151 compatible CPU Fan

Intel

1151 CPU

DIMM

SATA hard disk drive

Graphics card

Phillips (cross) screwdriver

SATA optical disc drive (optional)

1 bag of screws
