viii
STRIX H270F GAMING specifications summary
(continued on the next page)
CPU
Intel
®
Socket 1151 for 7th / 6th Generation Core™ i7/Core™ i5/Core™ i3/
Pentium
®
, and Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
H270 Chipset
Memory
4 x DIMM, max. 64GB DDR4 2400/2133 MHz Non-ECC, Un-buffered
Memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)*
Support Intel
®
Optane Memory**
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to Memory QVL(Qualified Vendors List) for details.
** Intel
®
Optane Technology in only supported when using 7th Generation Intel®
Processors.
** Refer to www.asus.com for the lastest Memory QVL(Qualified Vendors List).
Expansion slots
1 x PCIe 3.0/2.0 x16 slot (at x 16 mode)
1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode)
4 x PCIe 3.0/2.0 x1 slots
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort, HDMI, DVI ports
Supports DisplayPort 1.2 with max. resolution 4096 x 2304@60Hz
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz
Supports DVI with max. resolution 1920 x 1200@60Hz
Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
Supports up to 3 displays simultaneously
Maximum shared memory of 1024 MB (for iGPU exclusively)
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain
up to 3 displays
Multi-GPU
support
Supports AMD
®
CrossFireX™ Technology
Rear Panel I/O
Ports
1 x PS/2 keyboard/mouse combo port
1 x DisplayPort
1 x HDMI port
1 x DVI-D port
1 x Anti-surge LAN (RJ45) port
2 x USB 3.1 ports (1 Type-A, red; 1 Type-C, black at back panel)
2 x USB 3.0/2.0 ports ( blue, Type A)
4 x USB 2.0/1.1 ports
5 x Audio jacks
1 x Optical S/PDIF out
