Asus ROG STRIX H270F GAMING [81/113] Chapter 3

ASUS STRIX H270F GAMING

3-29

Chapter 3

The following four items appear only when you set Chassis Fan 1/2 Profile to [Manual].

Chassis Fan 1/2 Upper Temperature [70]

Use the <+> or <-> keys to adjust the upper limit of the CPU temperature. The values

range from 0°C to 75°C.

Chassis Fan 1/2 Max. Duty Cycle(%) [100]

Use the <+> or <-> keys to adjust the maximum chassis fan duty cycle. The values

range from 60% to 100%. When the chassis temperature reaches the upper limit, the

chassis fan will operate at the maximum duty cycle.

Chassis Fan 1/2 Middle Temperature [45]

Use the <+> or <-> keys to set the value for Chassis Fan Middle Temperature.

Chassis Fan 1/2 Middle Duty Cycle(%) [60]

Use the <+> or <-> keys to adjust the chassis fan middle duty cycle. The values range

from 60% to 100%.

Chassis Fan 1/2 Lower Temperature [40]

Use the <+> or <-> keys to adjust the chassis fans’ lower temperature. The values

range from 0°C to 75°C.

Chassis Fan 1/2 Min. Duty Cycle(%) [60]

Use the <+> or <-> keys to adjust the minimum chassis fan duty cycle. The values

range from 60% to 100%. When the CPU temperature is under the lower limit, the

chassis fan operates at the minimum duty cycle.

Ext. Fan(s) Configuration

The subitems in this menu allows you to congure the extension Q-Fan features.

Extension Fan 1/2/3 Q-Fan Control [DC Mode]

[PWM mode] Enables the chassis Q-Fan control in PWM mode for the 4-pin chassis fan.

[DC mode] Enables the chassis Q-Fan control in DC mode for the 3-pin chassis fan.

[Disabled] Disables the chassis Q-Fan control feature.

The following items appear only when you set the Extension Fan 1/2/3 Q-Fan Control to

[PWM Mode] or [DC Mode].

Extension Fan 1/2/3 Q-Fan Source [CPU]

This item controls the assigned fan according to the selected temperature source.

Conguration options: [CPU] [MotherBoard] [VRM] [PCH] [T_Sensor] [EXT_Sensor1]

[EXT_Sensor2] [EXT_Sensor3]

Extension Fan 1/2/3 Speed Low Limit [300 RPM]

This item allows you to disable or set the extension fan warning speed. Conguration

options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
