Brother MFC-465CN [120/182] Eu directive 2002 96 ec and en50419
![Brother MFC-465CN [120/182] Eu directive 2002 96 ec and en50419](/views2/1025845/page120/bg78.png)
108
Warning - This machine must be earthed. A
The wires in the mains lead are coloured in line with the following code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
If in any doubt, call a qualified electrician.
LAN connection A
CAUTION
DO NOT connect this product to a LAN connection that is subject to over-voltages.
Radio interference A
This product complies with EN55022 (CISPR Publication 22)/class B. When connecting the
machine to a computer, ensure that you use a USB cable which does not exceed 2.0 metres in
length.
EU Directive 2002/96/EC and EN50419 A
This equipment is marked with the above recycling symbol. It means that at the end of the life of
the equipment you must dispose of it separately at an appropriate collection point, and not place
it in the normal domestic unsorted waste stream. This will benefit the environment for all.
(European Union only)
European
Union Only
