Specifications
157
D
Interfaces D
1
Your machine has a full-speed USB 2.0 interface. This interface is compatible with Hi-Speed USB 2.0; however, the
maximum data transfer rate will be 12 Mbits/s. The machine can also be connected to a computer that has a USB 1.1
interface.
2
Third party USB ports are not supported for Macintosh
®
.
3
See the Network User's Guide for detailed network specifications.
USB
A USB 2.0 interface cable that is no longer than 2.0 m.
12
LAN cable
3
Ethernet UTP cable category 5 or greater.
