Brother MFC-465CN [166/182] Pictbridge

154

PictBridge D

Compatibility Supports the Camera & Imaging Products Association

PictBridge standard CIPA DC-001.

VIsit http://www.cipa.jp/pictbridge for more information.

Interface USB direct interface
