Indesit Moon SISL 129 S [3/48] Q indesit

Technical details

Model

SISL 129 S

Dimensions

59.5 cm wide

85 cm high

40 cm deep

Capacity

from 1 to 4,5 kg

Electric

connections

please refer to the technical data plate

fixed to the machine

Water

connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 40 litres

Spin speed

up to 1200 rpm

Control

programmes

according to

EN 60456

directive

programme ;

run with a load of 4,5 kg.

This appliance is compliant with the

following European Community

Directives:

- 73/23/CEE of 19/02/73 (Low

Voltage) and subsequent amendments

- 89/336/CEE of 03/05/89

(Electromagnetic Compatibility) and

subsequent amendments

- 2002/96/CE

65 - 100 cm

Connecting the drain hose

Connect the drain hose,

without bending it, to a

draining duct or a wall

drain situated between

65 and 100 cm from the

floor;

alternatively, place it

over the edge of a

basin, sink or tub,

fastening the duct

supplied to the tap (see

figure). The free end of

the hose should not be

underwater.

 We advise against the use of hose extensions; if it

is absolutely necessary, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

 the socket is earthed and complies with all

applicable laws;

 the socket is able to withstand the maximum

power load of the appliance as indicated in the

Technical data table (see opposite);

 the power supply voltage falls within the values

indicated in the Technical data table(see opposite);

 the socket is compatible with the plug of the

appliance. If this is not the case, replace the

socket or the plug.

 The machine must not be installed outdoors, even

in covered areas. It is extremely dangerous to leave

the appliance exposed to rain, storms and other

weather conditions.

 The mains socket must remain within easy reach

after the washing machine has been installed.

 Do not use extension cords or multiple sockets.

 The cable should not be bent or compressed.

 The power supply cable must only be replaced by

authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.
