![Asus ROG STRIX Z370-H GAMING [12/100] Rog strix z370 h gaming specifications summary](/img/pdf.png)
Asus ROG STRIX Z370-H GAMING [12/100] Rog strix z370 h gaming specifications summary
![Asus ROG STRIX Z370-H GAMING [12/100] Rog strix z370 h gaming specifications summary](/views2/1307906/page12/bgc.png)
xii
ROG STRIX Z370-H GAMING specifications summary
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,
ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11
EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log,
F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
Support DVD
contents
Drivers
ROG GameFirst IV*
ROG RAMCache II
ROG Clone Drive
ROG CPU-Z
Anti-virus software (OEM version)
ASUS WebStorage
ASUS Utilities
* ROG GameFirst IV is only available for Windows
®
10/8.1 64-bit.
Operating
system support
Windows
®
10 64-bit
Form factor
ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
