ROG STRIX Z370-H GAMING
2-15
Chapter 2
2.2 Motherboard rear and audio connections
2.2.1 Rear I/O connection
Rear panel connectors
1.
USB2.0ports1314 6. HDMI1.4b
2.
DVI-Dport 7. USB3.1Gen1ports12
3.
USB3.1Gen2Type-AportE12 8. USB3.1Gen1ports34
4.
PS/2keyboard/mousecomboport 9. OpticalS/PDIFOutport
5. Intel
®
LAN port (LAN1)* 10. AudioI/Oports**
* and ** : Refer to the tables on the next page for LAN port LEDs and audio port definitions.
• ThepluggedUSB3.1Gen1devicemayrunonxHCImodeorEHCImode,depending
on the operating system’s setting.
• USB3.1Gen1devicescanonlybeusedasdatastorageonly.
• Westronglyrecommendthatyouconnectyourdevicestoportswithmatchingdata
transferrate.PleaseconnectyourUSB3.1Gen1devicestoUSB3.1Gen1portsand
yourUSB3.1Gen2devicestoUSB3.1Gen2portsforfasterandbetterperformance
for your devices.
