Asus ROG STRIX Z370-H GAMING [26/100] Internal connectors
![Asus ROG STRIX Z370-H GAMING [26/100] Internal connectors](/views2/1307906/page26/bg1a.png)
1-12
Chapter 1: Product Introduction
Chapter 1
1.1.8 Internal connectors
1. Intel
®
Serial ATA 6 Gb/s connectors (7-pin SATA6G_12, SATA6G_34,
SATA6G_56)
TheseconnectorsconnecttoSerialATA6Gb/sharddiskdrivesviaSerialATA6Gb/s
signalcables.
IfyouinstalledSerialATAharddiskdrives,youcancreateaRAID0,1,5,and10
congurationwiththeIntel
®
RapidStorageTechnologythroughtheonboardIntel
®
Z370chipset.
• Theseconnectorsaresetto[AHCI]bydefault.IfyouintendtocreateaSerialATA
RAIDsetusingtheseconnectors,settheSATAModeitemintheBIOSto[Intel RST
Premium With Intel Optane System Acceleration (RAID)].
• BeforecreatingaRAIDset,refertothemanualbundledinthemotherboardsupport
DVD.
