3-18

Chapter 3: BIOS Setup

Chapter 3

SATA6G_1(Charcoal Black) - SATA6G_6(Charcoal Black)

This item allows you to enable or disable the selected SATA port.

Conguration options: [Disabled] [Enabled]

Hot Plug

These items appears only when the SATA Mode Selection is set to [AHCI] and allows

you to enable or disable SATA Hot Plug Support.

Conguration options: [Disabled] [Enabled]

3.6.7 Onboard Devices Configuration

The items in this menu allow you to switch between PCIe Lanes and congure onboard

devices.

HD Audio Controller

This item allows you to use the Azalia High Denition Audio Controller.

Conguration options: [Disabled] [Enabled]

M.2_1 Configuration: [Auto][SATA mode][PCIE mode]

[Auto] Auto-detects the M.2 device mode. If a SATA device is detected,

SATA6G_1 will be disabled.

[SATA mode] Only supports M.2 SATA devices. Please note that SATA6G_1 port cannot

be used in this mode.

[PCIE mode] Only supports M.2 PCIE devices.

Asmedia Back USB 3.1 Controller

This item allows you to enable or disable Asmedia USB 3.1.

Conguration options: [Disabled] [Enabled]

Intel LAN Controller

This item allows you to enable or disable the Intel LAN controllers.

Conguration options: [Disabled] [Enabled]

3.6.8 APM Configuration

The items in this menu allow you to set system wake and sleep settings.

ErP Ready

This item allows you to switch off some power at S4+S5 or S5 to get the system ready for

ErP requirement. When set to [Enabled], all other PME options are switched off.

Conguration options: [Disabled] [Enable(S4+S5)] [Enable(S5)]

3.6.6 PCH-FW Configuration

This item allows you to congure the rmware TPM.
