xiii
Package contents
Check your motherboard package for the following items.
Motherboard 1 x ROG STRIX Z370-H GAMING motherboard
Cables
1 x 2-in-1 SATA 6Gb/s cables
1 x SLI™ HB BRIDGE (2-WAY-M)
Accessories
1 x I/O shield
1 x CPU Installation tool
1 x ROG cable label set
1 x ROG Strix sticker
1 x M.2 Screw Package
1 x ASUS fan holder
Application drive 1 x ROG motherboard support DVD
Documentation 1 x User guide
If any of the above items is damaged or missing, contact your retailer.
