Liebherr ICBN 3376 [10/18] Drawers with cushioners
![Liebherr ICBN 3376 [10/18] Drawers with cushioners](/views2/1321624/page10/bga.png)
u
Press the Up setting button, freezer compartment
Fig. 2 (10)
the number of times required for b to flash in the display.
u
To confirm: briefly press the SuperFrost button.
u
To set the temperature higher: press Up button, freezer
compartment
Fig. 2 (10)
.
u
To set the temperature lower: press Down button, freezer
compartment
Fig. 2 (11)
.
u
To confirm: press SuperFrost button.
w
The temperature slowly adjusts to the new value.
u
To deactivate the setting mode: press On/Off button, freezer
compartment
Fig. 2 (8)
.
-or-
u
Wait for 5 minutes.
w
The temperature is indicated again in the temperature
display.
5.5.7 Drawers with cushioners
Fig. 13
u
Pull out the drawer, lift it at the back and draw it forwards for
removal.
u
Push the rails in again!
Fig. 14
u
Push the rails in.
u
Attach the drawer and push it in until it engages audibly at
the back.
5.5.8 Humidity control plate
u
To remove the humidity control plate: Having removed the
drawers, carefully draw the plate forwards and lower it for
removal.
5.5.9 Using the FlexSystem
The FlexSystem helps you store and organise your food in a
clear and flexible way. It lets you clearly divide your food into
fruit, vegetables or by use-by dates, for example.
Fig. 15
u
You can take the FlexSystem apart for cleaning.
5.6 Freezer compartment
You can store frozen food, make ice cubes and freeze fresh
food in the freezer compartment.
5.6.1 Freezing food
The rating plate indicates the maximum quantity of fresh food
you can freeze within 24 hours (see Appliance at a glance)
under “Freezing capacity ... kg/24h”.
The maximum load of frozen food for the drawers is 25 kg each
and for the shelves 35 kg each.
A vacuum is generated after the door is closed. After closing
the door, wait for about 1 minute and then it opens more easily.
CAUTION
Risk of injury due to broken glass!
Bottles and cans containing drinks may burst when being
frozen. This applies particularly to sparkling drinks.
u
Do not freeze bottles and cans containing drinks!
In order that the food is rapidly frozen through to the core, do
not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg
- Meat up to 2.5 kg
u
Pack the food in portions in freezer bags, reusable plastic,
metal or aluminium containers.
5.6.2 Thawing food
- in the refrigerator compartment
- in a microwave oven
- in a conventional or fan oven
- at room temperature
u
Remove only as much food as is required. Use thawed food
as quickly as possible.
u
Food once thawed should be re-frozen only in exceptional
cases.
5.6.3 Setting the temperature in the freezer
compartment
The appliance is pre-set for normal operation.
Control
10 * Depending on model and options
