Liebherr ICBN 3376 [14/18] Cleaning the icemaker
![Liebherr ICBN 3376 [14/18] Cleaning the icemaker](/views2/1321624/page14/bge.png)
NOTICE
Incorrect cleaning damages the appliance!
u
Do not use cleaning agents in concentrated form.
u
Do not use any scouring or abrasive sponges or steel wool.
u
Do not use any sharp or abrasive cleaning agents, nor any
that contain sand, chloride or acid.
u
Do not use chemical solvents.
u
Do not damage or remove the type plate on the inside of the
appliance. It is important for the customer service.
u
Do not pull off, bend or damage cables or other compo-
nents.
u
Do not allow any cleaning water to enter the drain channel,
ventilation grille or electrical parts.
u
Please use soft cleaning cloths and a universal pH-neutral
cleaning agent.
u
Please use cleaning and care products suitable for contact
with foodstuffs in the appliance interior.
u
Empty appliance.
u
Pull out the power plug.
u
Clean plastic outer and inner surfaces with lukewarm
water and a little washing-up liquid.
u
Clean drain hole: Remove deposits
with a narrow instrument, e.g. a
cotton bud.
u
Most of the parts can be dismantled for cleaning: see the
relevant chapter.
u
Clean drawers by hand with lukewarm water and a little
washing up liquid.
u
All the other fittings can be put in the dishwasher.
u
Only use a damp cloth to clean the telescopic rails. The
grease in the runners is for lubrication purposes and must
not be removed.
After cleaning:
u
Wipe dry the appliance and items of equipment.
u
Connect the appliance and switch it on again.
u
Switch on SuperFrost (see 5.6.4) .
When the temperature is sufficiently cold:
u
Put the food back inside.
6.4 Cleaning the IceMaker*
The drawer of the IceMaker has to be emptied and slid in.
u
To activate the setting mode: press the SuperFrost button
Fig. 2 (12)
for about 5 s.
w
The display indicates c.
w
The menu symbol
Fig. 2 (16)
shines.
u
Using the Up setting button, freezer compartment
Fig. 2 (10)
/ Down setting button, freezer compartment
Fig. 2 (11)
select I.
u
To confirm: press the SuperFrost button
Fig. 2 (12)
.
u
Using the Up setting button, freezer compartment
Fig. 2 (10)
/ Down setting button, freezer compart-
ment
Fig. 2 (11)
select Ic.
u
To confirm: press the SuperFrost button
Fig. 2 (12)
.
u
To deactivate the setting mode: press the On/Off button,
freezer compartment
Fig. 2 (8)
.
-or-
u
Wait for 2 minutes.
w
The temperature is indicated again in the temperature
display.
u
Remove the drawer.
u
Clean the ice cube tray and drawer with warm water. If
necessary, use mild washing-up liquid. Then rinse.
u
Slide in the drawer again.
u
Leave the IceMaker switched off in this position.
-or-
NOTICE
Rinse agent residue in the ice compartment and drawer.
Nausea or irritation of the mucous membrane.
u
Remove rinse agent residue: Discard the first three batches
of ice cubes.
u
Switch the IceMaker on (see 5.6.11) .
6.5 Customer service
First check whether you can correct the fault yourself by refer-
ence to the list (see Malfunction). If this is not the case, please
contact the customer service whose address is given in the
enclosed customer service list.
WARNING
Risk of injury if repair work is not carried out professionally!
u
Have any repairs and action - not expressly specified - on
the appliance and mains cable carried out by service
personnel only. (see Maintenance)
u
Read the appliance
designation
Fig. 21 (1)
, service
No.
Fig. 21 (2)
and
serial No.
Fig. 21 (3)
off the type plate
located inside the
appliance on the left-
hand side.
Fig. 21
u
Notify the customer service, specifying the fault, appliance
designation
Fig. 21 (1)
, service No.
Fig. 21 (2)
and serial No.
Fig. 21 (3)
.
w
This will help us to provide you with a faster and more accu-
rate service.
u
Keep the appliance closed until the customer service
arrives.
w
The food will stay cool longer.
u
Pull out the mains plug (not by pulling the connecting cable)
or switch off the fuse.
7 Malfunctions
Your appliance is designed and manufactured for a long life
span and reliable operation. If a malfunction nonetheless
occurs during operation, check whether it is due to a handling
error. In this case you will have to be charged for the costs
incurred, even during the warranty period. You may be able to
rectify the following faults yourself:
Appliance does not work.
→
The appliance is not switched on.
u
Switch on the appliance.
→
The power plug is not properly inserted in the wall socket.
u
Check power plug.
→
The fuse of the wall socket is not in order.
u
Check fuse.
The compressor runs for a long time.
→
The compressor switches to a low speed when little cold is
needed. Although the running time is increased as a result,
energy is saved.
u
This is normal in energy-saving models.
→
SuperFrost is activated.
Malfunctions
14 * Depending on model and options
