Liebherr ICBN 3376 [15/18] Malfunctions
![Liebherr ICBN 3376 [15/18] Malfunctions](/views2/1321624/page15/bgf.png)
u
The compressor runs for longer in order to rapidly cool the
food. This is normal.
→
SuperCool is activated.
u
The compressor runs for longer in order to rapidly cool the
food. This is normal.
A LED on the bottom rear of the appliance (at the
compressor) flashes repeatedly every 5 seconds*.
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
Excessive noise.
→
Due to the various speed steps, speed-regulated* compres-
sors can generate different running noises.
u
The sound is normal.
A bubbling and gurgling noise.
→
This noise comes from the refrigerant flowing in the refriger-
ation circuit.
u
The sound is normal.
A quiet clicking noise.
→
The noise is produced whenever the refrigeration unit
(motor) automatically switches on or off.
u
The sound is normal.
A hum. It is briefly a little louder when the refrigeration
unit (the motor) switches on.
→
The refrigeration increases automatically when the
SuperFrost, function is activated, fresh food has just been
placed in the appliance or the door has been left open for a
while.
u
The sound is normal.
→
The refrigeration increases automatically when the
SuperCool function is activated, fresh food has just been
placed in the appliance or the door has been left open for a
while.
u
The sound is normal.
→
The ambient temperature is too high.
u
Solution: (see 1.2)
A low hum.
→
The sound is produced by air flow noise of the fan.
u
The sound is normal.
Vibration noises
→
The appliance is not standing firmly on the floor. As a result
objects and adjacent units start to vibrate when the refriger-
ator is running.
u
Check the installation and realign the appliance.
u
Keep bottles and jars apart.
Flow sound at the soft stop mechanism.
→
The noise is produced when the door is opened and
closed.
u
The sound is normal.
The temperature display indicates: F0 to F9
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
The temperature display reads:FE*
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
Power failure flashes in the temperature display
. The
highest temperature reached during power failure is indi-
cated in the temperature display.
→
The freezer temperature rose too high over the last hours or
days due to a power failure or power interruption. When the
power interruption is over, the appliance will continue to
operate in the last temperature setting.
u
To cancel the display of the warmest temperature: press
alarm button
Fig. 2 (14)
.
u
Check the quality of the food. Do not consume spoiled food.
Do not re-freeze thawed food.
DEMO shines in the temperature display.
→
The demo mode is activated.
u
Please contact the after-sales service (see Maintenance).
The outer surfaces of the appliance are warm*.
→
The heat of the refrigeration circuit is used to prevent
condensate from forming.
u
This is normal.
The IceMaker cannot be switched on. *
→
The appliance and therefore the IceMaker are not
connected.
u
Connect the appliance to the mains (see Putting into opera-
tion).
The IceMaker does not make any ice cubes.*
→
The IceMaker is not switched on.
u
Switch on the IceMaker.
→
The drawer of the IceMaker is not properly closed.
u
Close the drawer properly.
→
The water connection is not open.
u
Open the water connection.
→
The water intake to the IceMaker has been interrupted.
u
Check the water connection (see Water Connection in the
Fitting Instructions).*
u
Check the hosing (see Water Connection in the Fitting
Instructions).*
→
The screen located in the end piece of the water intake
hose or the screen located in the connecting piece on the
appliance is blocked.
u
Clean the screens.
The temperature is not cold enough.
→
The door of the appliance is not properly closed.
u
Close the door of the appliance.
→
Insufficient ventilation.
u
Keep ventilation grille clear, and clean it.
→
The ambient temperature is too high.
u
Solution: (see 1.2) .
→
The appliance was opened too frequently or for too long.
u
Wait to see whether the appliance reaches the required
temperature by itself. If not, please contact the after sales
service (see Maintenance).
→
Too much fresh food was placed inside without SuperFrost.
u
Solution: (see 5.6.4)
→
The temperature is incorrectly set.
u
Set the temperature to a colder setting and check after 24
hours.
→
The appliance is too close to a source of heat (stove, heater
etc).
u
Change the position of the appliance or the source of heat.
→
The appliance was not inserted properly into the recess.
u
Check whether the appliance was inserted correctly and
the door closes properly.
The internal light does not come on.
→
The appliance is not switched on.
u
Switch the appliance on.
→
The door was open for longer than 15 minutes.
u
The internal light switches itself off automatically after about
15 minutes if the door is open.
→
The LED illumination is faulty or the cover is damaged:
WARNING
Risk of injury due to electric shock!
Live parts are located under the cover.
u
Have the LED interior light changed or repaired only by the
customer service or by specialized personnel trained for the
purpose.
Malfunctions
* Depending on model and options 15
