![Liebherr ICBN 3376 [16/18] Switching off the refrigerator compart ment with biofresh compartment](/img/pdf.png)
Liebherr ICBN 3376 [16/18] Switching off the refrigerator compart ment with biofresh compartment
![Liebherr ICBN 3376 [16/18] Switching off the refrigerator compart ment with biofresh compartment](/views2/1321624/page16/bg10.png)
WARNING
Danger of injury by LED lamp!
The light intensity of the LED illumination corresponds to laser
class 1/1M.
If the cover is defective:
u
Do not look into the illumination with optical lenses from the
immediate proximity. This can cause injury to the eyes.
The door gasket is defective or should be replaced for
other reasons.*
→
In some units, the seal around the door can be replaced.
You will not need any special tools to do this.
u
Please contact the after-sales service (see Maintenance).
The unit has iced up or condensation has formed.*
→
The door seal may have also slipped out of its groove.
u
Check to ensure that the door seal is seated properly in the
groove.
8 Decommissioning
8.1 Switching off the appliance
Note
u
If the appliance cannot be switched off, the Child Safety
function is still activated (see 5.1) .
8.1.1 Switching the whole appliance off via the
freezer compartment
u
Press the freezer compartment On/Off button
Fig. 2 (8)
for
approx. 2 seconds.
w
A long beep sounds.
w
The temperature displays are dark.
w
The appliance is switched off.
8.1.2 Switching off the refrigerator compart-
ment with BioFresh compartment
Note
Before going on holiday, or other prolonged periods of non-use
u
You can switch the fridge section with BioFresh on/off sepa-
rately.
u
Press the refrigerator compartment On/Off button
Fig. 2 (1)
for approx. 2 seconds.
w
The fridge temperature display
Fig. 2 (2)
is dark.
w
The fridge and BioFresh section are off.
8.2 Taking the appliance out of service*
u
Empty the appliance.
u
Put the IceMaker in the cleaning position (see Mainte-
nance).
u
Switch off the appliance (see Decommissioning).
u
Remove mains connector.
u
Clean the appliance (see 6.3) .
u
Leave the door open to prevent odour.
9 Disposing of the appliance
The appliance contains some reusable materials
and should be disposed of properly - not simply
with unsorted household refuse. Appliances which
are no longer needed must be disposed of in a
professional and appropriate way, in accordance
with the current local regulations and laws.
When disposing of the appliance, ensure that the refrigeration
circuit is not damaged to prevent uncontrolled escape of the
refrigerant it contains (data on type plate) and oil.
u
Disable the appliance.
u
Pull out the plug.
u
Cut through the connecting cable.
Decommissioning
16 * Depending on model and options
