u
The maximum load of frozen
food for the drawers is 25 kg
each and for the shelves
35 kg each.
5.6.8 Information system
Fig. 16
(1) Bread (4) Vegetables
(2) Ice cream (5) Meat
(3) Fish (6) Fruit
Fig. 17
*
(1) Ice cubes
The figures indicate the storage time in months for several
types of frozen food in each case. Storage times given are
guide times.
5.6.9 Ice cube tray*
Fig. 18
When the water is frozen:
u
Hold ice cube tray under hot water for a short time.
u
Remove the lid.
u
Gently turn the ends of the ice cube tray in opposite direc-
tions and release the cubes.
Dismantling the ice cube tray
Fig. 19
u
You can take the ice cube tray apart for cleaning.
5.6.10 Cold storage accumulators
The cold storage accumulators prevent the temperature from
rising too fast in the event of power failure.
Using cold storage accumulators*
u
Place the frozen cold storage
accumulators on the frozen food
in the upper front area of the
freezer compartment.
Using cold storage accumulators*
u
Freeze and store the cold storage accumu-
lators in the ceiling of the freezer compart-
ment.
With the top drawer
removed:
u
to insert cold storage accu-
mulators: slide cold
storage accumulator into
the top back of the freezer
compartment ceiling and
snap into place at the front.
With the top drawer
removed:
u
to remove cold storage
accumulators: take hold of
the cold storage accumu-
lator at the side and press
it down for removal.
5.6.11 IceMaker*
The IceMaker is in the top drawer of the freezer compartment.
The drawer is marked “IceMaker”.
Make certain that the following conditions are met:
-
The appliance is level.
-
The appliance is connected.
-
The freezer compartment is switched on.
-
The IceMaker is connected to the water supply.
Switching on the IceMaker*
Fig. 20
u
Pull out the drawer.
u
Press the On/Off button
Fig. 20 (1)
so that the LED
Fig. 20 (2)
shines.
u
Push in the drawer.
w
The IceMaker symbol
Fig. 2 (18)
shines.
Note
u
The IceMaker produces ice cubes only if the drawer is fully
closed.
Producing ice cubes*
The production capacity depends on the freezer temperature.
The lower the temperature, the more ice cubes can be
produced in a specific period.
Control
12 * Depending on model and options
