Liebherr ICBN 3376 [7/18] Door racks
![Liebherr ICBN 3376 [7/18] Door racks](/views2/1321624/page7/bg7.png)
5.4.6 Using the sectioned shelf
u
Slide the sectioned shelf
under, as shown in the
illustration.
Fig. 4
u
The glass plate (1) with pull-out stops must be at the front so
that the stops (3) face downwards.
5.4.7 Using adjustable bottle shelf
At the base of the refrigerator compartment, the integrated
bottle shelf or alternatively the glass shelf can be used:
u
Using the bottle shelf: to
save space, store the glass
shelf under the bottle shelf.
u
Place the bottles with the
base pointing backwards
facing the rear wall.
If the bottles project beyond
the bottle shelf:
u
set the lower door rack one
position higher.
5.4.8 VarioSafe*
The VarioSafe provides space for small items of food and pack-
ages, tubes and jars.
Using VarioSafe*
Fig. 5
u
The VarioSafe drawer can be taken out and pushed in at two
different heights.
u
The VarioSafe can also be
height-adjusted as a whole.
u
To remove them completely,
set them at an angle and pull
towards you.
Dismantling VarioSafe*
Fig. 6
u
The VarioSafe can be dismantled for cleaning.
5.4.9 Door racks
Moving the storage rack
Fig. 7
Fig. 8
You can use just one or both boxes. To store oversized bottles,
just suspend one box over the bottle rack. Store the other box
in the holder.
u
Re-positioning the
boxes: Lift them for
removal and re-posi-
tion them as required.
Control
* Depending on model and options 7
