Safety information that appears in this manual is identified by
the following signal word panels:
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to
personal injury.
NOTICE
CAUTION
WARNING
INTRODUCTION
The Hatco Multi-Product Warming Station holds hot fried
products and other pre-heated food at serving temperatures in
kitchen work areas. This station will keep food at optimum
serving temperatures without affecting quality.
The Multi-Product Warming Station features easy access to the
food product and incorporates Hatco’s precise temperature
control to safely hold foods longer. The semi-enclosed chamber
is equipped with pre-focused infrared heat from above and a
thermostatically-controlled heated base to extend the holding
times of the food product. The ceramic heating elements and
the base blanket heating element are guaranteed against
burnout and breakage for one year.
The Hatco Multi-Product Warming Station is a product of
extensive research and field testing. The materials used were
selected for maximum durability, attractive appearance, and
optimum performance. Every unit is inspected and tested
thoroughly prior to shipment.
Important Owner Information ..............................................2
Introduction...........................................................................2
Important Safety Information...............................................3
Model Description.................................................................4
Model Designation................................................................4
Specifications........................................................................5
Plug Configurations.............................................................5
Electrical Rating Chart ........................................................5
Dimensions .........................................................................5
Installation .............................................................................6
General ...............................................................................6
Operation...............................................................................7
General ...............................................................................7
Maintenance ..........................................................................8
General ...............................................................................8
Daily Cleaning .....................................................................8
Replacing Display Light Bulbs.............................................8
Troubleshooting Guide ........................................................8
Options and Accessories...................................................10
Hatco Limited Warranty......................................................11
Authorized Parts Distributors ............................Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number (specification label
located on the back of the unit), voltage, and purchase date of
the unit in the spaces below. Please have this information
available when calling Hatco for service assistance.
Model No. ________________________________________
Serial No. ________________________________________
Voltage __________________________________________
Date of Purchase __________________________________
Register your unit!
Completing online warranty registration will prevent delay in
obtaining warranty coverage. Access the Hatco website at
www.hatcocorp.com, select the Parts & Service pull-down
menu, and click on “Warranty Registration”.
Business
Hours: 8:00
AM to 5:00 PM Central Standard Time (CST)
(Summer Hours: June to September—
8:00
AM to 5:00 PM CST Monday–Thursday
8:00
AM to 2:30 PM CST Friday)
Telephone: 800-558-0607; 414-671-6350
E-mail: partsandservice@hatcocorp.com
Fax: 800-690-2966 (Parts and Service)
414-671-3976 (International)
Additional information can be found by visiting our web site at
www.hatcocorp.com.
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling 800-558-0607.
CONTENTS
