8.0 OPERATING CONDITIONS
To obtain the best product results and consistent operation,
Make sure the depositor is used on a level floor.
Ensure flat trays of consistent length, width, material
and edge dimensions are used.
Ensure undamaged nozzles and templates are used.
Keep the machine clean.
