FG078 –OMEGA TOUCH LMC 09-12 RAC
22
SELECT PRODUCT TYPE
SELECT PRODUCT TO DEPOSIT OR TO CREATE NEW PROGRAM
DROP WITH
TWIST
ARC
STRIP
SHEETING
REVERSE STRIP
DROP
CHOOSE
LANGUAGE
MACHINE SETUP
PRODUCT
EDITING
COPYING
DELETING
PROGRESS TO
NEXT SCREEN
SHELL
PASSWORDS ARE REQUIRED FOR
THESE FUNCTIONS. SEE PART 8
TO LAST
SCREEN
TOWER
WITH TWIST
TOWER
1
TOUCH THE SCREEN FOR THE TYPE OF PRODUCT REQUIRED
THEN TO MOVE TO NEXT SCREEN
MULTIDROP
WITH TWIST
STRIP WITH
TWIST
SPIRAL
MULTIDROP
HIGHLIGHT BOX
APPEARS TO SHOW
SELECTED PRODUCT
WHEN SCREEN
TOUCHED
THESE BUTTONS
CONTROL CHANGES
TO THE MACHINE
