![Mono Omega Touch 400 [6/63] Dimensions](/img/pdf.png)
Mono Omega Touch 400 [6/63] Dimensions
![Mono Omega Touch 400 [6/63] Dimensions](/views2/1334004/page6/bg6.png)
FG078 –OMEGA TOUCH LMC 09-12 RAC
6
2.0 DIMENSIONS
Omega
Touch
890mm
690mm
1210mm
860mm
EXTENDED HOPPER 980MM
470mm
1330mm
1510mm
898mm MAX
818mm MIN
1451mm (extended capacity hopper)
1334mm (Standard capacity hopper)
2111mm (580mm Extended capacity hopper)
1981mm (400mm + 450mm Extended capacity hopper)
1994mm (580mm Standard capacity hopper)
1864mm (400mm + 450mm Standard capacity hopper)
