1. GENERAL PRECAUTIONS

La NORDICA S.p.A. responsibility is limited to the supply of the appliance.

The installation must be carried out scrupulously according to the instructions provided in this manual and the rules of the profession.

Installation must only be carried out by a qualied technician who works on behalf of companies suitable to assume the entire responsibility

of the system as a whole.

La NORDICA S.p.A. declines any responsibility for the product that has been modied without written authorisation as well as

for the use of non-original spare parts.

respect for such precautions.

2. INSTALLATION REGULATIONS

Installation of the product and auxiliary equipment in relation to the heating system must comply with all current Standards and Regulations

and to those envisioned by the law.

The installation and the relating to the connections of the system, the commissioning and the check of the correct functioning must

be carried out in compliance with the regulations in force by authorised professional personnel with the requisites required by the law,

being national, regional, provincial or town council present in the country within which the appliance is installed, besides these present

instructions.

Installation must be carried out by authorised personnel who must provide the buyer with a system declaration of conformity and will

assume full responsibility for nal installation and as a consequence the correct functioning of the installed product.

• Make sure that the ue and the pipes to which the appliance will be connected are suitable for its operation. It is NOT allowed the

connection of various appliances to the same chimney.

• The diameter of the opening for connection to the chimney must at least correspond to the diameter of the ue gas pipe. The

opening must be equipped with a wall connection for the insertion of the exhaust pipe and a rosette.

• Always leave the recommended air pocket between the appliance and the walls, rear and side min. (see MARKING INFORMATION).

• Establish the type of ventilation (natural or forced) see chapter VENTILATION HOOD OR ADJACENT LOCAL.

• By means of the adjustable feet and using a level make sure that the device is perfectly levelled to allow a correct sliding of the door.

After testing the proper working of the appliance, some days from the installation, it is possible to proceed with the construction

of its aesthetic covering.

WARNING: During the surround building operations it must kept in mind possible and subsequent electrical installed parts maintenance

When installing the appliance, the following safety measures must be observed:

a) In order to ensure sufcient thermal insulation, respect the minimum safety distance from objects or furnishing components ammable

and sensitive to heat and from materials with ammable structure (see CE MARKING INFORMATION - Picture 7 at page 43). All the

minimum safety distances are shown on the product data plate and lower values must not be used.

b) in front of the furnace door, in the radiation area, there must be no ammable or heat-sensitive objects or material at a distance of

less than 80 cm. This distance can be reduced to 40 cm where a rear-ventilated, heat-resistant protection device is installed in front

of the whole component to protect;

c) If the product is installed on a no totally refractory oor, one must foresee a reproof background. The oors made of inammable

material, such as moquette, parquet or cork etc., must be covered by a layer of no-inammable material (size according to

regional law) (see Picture 1 at page 40).
