La Nordica Focolare 60 Piano [17/56] First aid measures

During the combustion, thermal air is emitted by involving the heating of areas, door and glass hearth, of the door handles or controls,

of the smokes pipe and, in case, of the front part of appliance. Avoid to touch those parts without a protective clothing or without

accessory tools (gloves resistant to heat, control devices).

Ensure children are aware of these dangers and keep them away from the furnace when it is on.

Warn children that the device becomes very hot and that it must not be touched.

When using the wrong fuel or one which is too damp, due to deposits present in the ue, a ue re is possible.

3.1. FIRST-AID MEASURES

Should any re arise in the stack or in the ue:

a) Close the feeding door.

3.2. BEAM PROTECTIONS

Considering the irradiation of the hearth, it is necessary to be particularly careful in protecting the beams while designing your stack.

Consider the proximity of beams to the external surfaces of the hearth, on one side, and the irradiation of the glass door, usually very close

to the beams, on the other side. In any case, it has to be considered that the internal or lower surfaces of this beam in ammable material

must not come in contact with temperatures higher than 65 °C. Picture 2 at page 40 gives some examples of execution.

WARNING: We cannot be made liable for a wrong operation of the plant, when it does not comply with the provisions of these

instructions or when it uses additional products not suitable for this device.

4. TECHNICAL DESCRIPTION

Denition: product according to EN 13240 The appliance works as an intermittent operating appliance.

The devices La Nordica are suitable to heat living spaces for some periods. As fuel, wood logs are used. .

yield and a reduction of emissions of unburnt gases.

The replace is equipped with a sight door with ceramic glass (resistant up to 700°C). This allows a charming sight on burning ames.

Moreover, in this way, any possible leak of sparks and smoke is avoided.

Room heating takes place:

a) By irradiation: through the panoramic glass and the external hot surfaces of the stove, the heat is radiated into the environment;

b) By natural convection: the passage of air through the coating and the covering hood releases heat in the room.

The device is equipped with registers of primary and secondary air.

1A- PRIMARY air register

With the primary air control (Picture 8 at page 44 ) is adjusted the passage of air through the ash drawer and the grate in the fuel

direction. The primary air is necessary for the combustion process. The ash drawer must be regularly emptied, so that the ash does not

NORMAL OPERATION. Through this register it is possible to adjust the power of the device.

Leaving it slightly open, according to the ue of the device, it is possible to keep the glass clean.

The adjustment of the registers necessary to reach the rated caloric yield is the following one:

Fuel PRIMARY air SECONDARY air TERTIARY AIR

Wood CLOSED OPEN PRE-ADJUSTED

FOCOLARI IN GHISA

6097000 - IT-EN-DE-FR 17
