TERMOCAMINO 650 - 800

18 6098000 - IT-EN-DE-FR

must never be lit in the presence of gaseous emissions or vapours (for example: glue for linoleum, petrol, etc,). Do not place ammable

materials in the vicinity of the appliance.

During the combustion, thermal air is emitted by involving the heating of areas, door and glass hearth, of the door handles or controls,

of the smokes pipe and, in case, of the front part of appliance. Avoid to touch those parts without a protective clothing or without

accessory tools (gloves resistant to heat, control devices).

Ensure children are aware of these dangers and keep them away from the furnace when it is on.

Warn children that the device becomes very hot and that it must not be touched.

2

d) Seek immediate intervention of FIRE BRIGADE.

DO NOT EXTINGUISH FIRE USING WATER JETS. When the ue does not burn any more please arrange an examination by a specialist

in order to nd possible cracks and permeable points.

3.2. BEAM PROTECTIONS

Considering the irradiation of the hearth, it is necessary to be particularly careful in protecting the beams while designing your stack.

Consider the proximity of beams to the external surfaces of the hearth, on one side, and the irradiation of the glass door, usually very close

to the beams, on the other side. In any case, it has to be considered that the internal or lower surfaces of this beam in ammable material

must not come in contact with temperatures higher than 65 °C. Picture 3 at page 46 gives some examples of execution.

WARNING: We cannot be made liable for a wrong operation of the plant, when it does not comply with the provisions of these

bed and removable grille are both made of cast iron. The appliance is equipped with a smoke deector, inserted between the two upper

cylindrical pipes, which is easy to remove for quick and handy cleaning of the inside part. The circular combustion chamber has a perforated

central back piece in cast iron. Pre-heated air reaches the inside of the hearth through these holes, thus providing post-combustion with

an increase in yield and a reduction of emissions of unburnt gasses.

The door with viewing window is tted on extendible ball bearing guides that guarantee the sturdy, quiet, and reliable operation of the

appliance. The counterweight for door raising is supported by two sturdy chains with respective pinions.

The ceramic glass window (resistant up to 700°C) of the door provides a lovely view of the burning ames and prevents sparks and smoke

from getting out. Room heating takes place:

a) by radiation: the heat is radiated into the environment through the panoramic window and the hot external surfaces of the thermo-

replace;

cannot hinder the intake of primary air for the combustion. Primary air is also necessary to keep re live. During the combustion of

wood, the primary air register must be opened only a few, since otherwise the wood burns quickly and the device can overheat.

The adjustment of the registers necessary to reach the rated caloric yield is the following one:

5. FLUE

Essential requirements for a correct operation of the device:
