TERMOCAMINO 650 - 800

20 6098000 - IT-EN-DE-FR

150 cm

internal air intake for the fan, if present (C);

* (For a better comfort and corresponding oxygenation of environment, the combustion air can be directly withdrawn at the outside through

a junction (B1) which is to be connected with a exible pipe (not furnished)for the external air intake. The connection pipe must be at with

a minimum diameter of (B1 Picture 11 at page 50), a maximum length of 4 m and with no more than 3 bends. If there is a direct connection

with the outside it must be endowed with a special windbreak.)

6. ALLOWED / NOT ALLOWED FUELS

Allowed fuels are logs. Use exclusively dry logs (max. content of water 20%). Maximum 3 logs should be loaded. The pieces of wood

should have a length of ca. 20-30 cm and a maximum circumference of 30-35 cm.

Compressed not worked-out wood briquettes must be used carefully to avoid overheating that may damage the device, since

these have a very high caloric value.

The wood used as fuel must have a humidity content lower than the 20% and must be stored in a dry place. Humid wood tends to burn

less easily, since it is necessary a greater quantity of energy to let the existing water evaporate. Moreover, humid content involves

the disadvantage that, when temperature decreases, the water condensates earlier in the hearth and therefore in the stack causing a

remarkable deposit of soot with following possible risk of re of the same.

Fresh wood contains about 60% of H

O, therefore it is not suitable to be burnt.

It is necessary to place this wood in a dry and ventilated place (for example under a roong) for at least two years before using it.

Besides others, it is not possible to burn: carbon, cuttings, waste of bark and panels, humid wood or wood treated with paints,

plastic materials; in this case, the warranty on the device becomes void.

Paper and cardboard must be used only to light the re.

The combustion of waste is FORBIDDEN and would even damage the appliance and the ue, causing health damages and claims by

the neighborhood owing to the bad smell. The wood is not a fuel which allows a continuous operation of the appliance, as consequence

the heating all over the night is not possible.

Variety Kg/mc kWh/kg moistness 20%

Beech

750 4,0

Oak

900 4,2

Elm

640 4,1

Poplar

470 4,1

Larch*

660 4,4

Spruce*

450 4,5

Scots pine *

550 4,4

* RESINOUS WOOD NOT SUITABLE FOR THE BURNING

ATTENTION : the continuous and protracted use of aromatic wood (eucalyptus, myrtle etc.) quickly damages the cast iron parts

(cleavage) of the product.

7. LIGHTING

ATTENTION: never light for any reason if the installation is not completely full of water in order to avoid a serious damage of

the whole structure. IABSOLUTELY DO NOT LIGHT THE FIRE IN THE THERMO-FIREPLACE IN THE TOTAL OR PARTIAL

ABSENCE OF WATER (NOT EVEN FOR CHECKING), AS IT COULD BE IRREMEDIABLY RUINED. IN SUCH CASE THE

WARRANTY ON THE APPLIANCE IS VOIDED.

Before installing the facing and lighting the thermo-replace, it must be loaded and the system lled from the open expansion tank by

means of the natural fall of the water (see chapter. SYSTEM CONNECTION AND FILLING).

After ensuring that at least one radiator is always open, open the door and load a small quantity of wood.

To light the re, it is suggested to use small wood pieces together with paper or other traded lighting means. It is FORBIDDEN to use

any liquid substance as for ex. alcohol, gasoline, oil and similar. Never switch on the device when there are combustible gases

in the room.

The openings for air (primary and secondary) must be opened together (you must open the eventual Ignition control, and buttery valve

placed on the pipe of smokes exhaust). When the wood starts burning, you may load other fuels and adjust the air for combustion

according to the instructions on paragraph TECHNICAL DESCRIPTION.

Please always be present during this phase. Never overload the appliance (see the technical table - max. quantity of fuel that can be

loaded / hourly consumption). Too much fuel and too much air for combustion can cause overheating and therefore damage the

same.

After the rst ignition you can smell bad odours (owing to the drying of the glue used in the garnitures or of the paint) which disappear after

a brief using of the appliance. A good ventilation of the room should always be guaranteed.

ATTENTION: during the rst lightings there could be a solid smokes condensation with a small escape of water from the thermo-

replace: this event will expire in a very short time but if it persists it will be necessary to check the chimney draught.

To perform a correct rst lighting of the products treated with paints for high temperature, it is necessary to know the following information:

• the construction materials of the involved products are not homogeneous, in fact there are simultaneously parts in cast iron, steel,

refractory material and majolica;

• the temperature to which the body of the product is subject is not homogeneous: from area to area, variable temperatures within

the range of 300°C - 500°C are detected;

• during its life, the product is subject to alternated lighting and extinguishing cycles in the same day, as well as to cycles of intense

use or of absolute standstill when season changes;
