K01068 | v. 02/09/2016 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
9
7.3. Where to use
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model Height Width Depth
K3, K3 ELITE 20.27 515 7.28
185
15.15 385
K3, K3 ELITE
Mini-hopper (optional)
17.32 440 7.28
185
15.15 385
K6, K6 SILENZIO, K6 PB 25.78 655 9.25 235 16.53 420
K8 SILENZIO 25 655 9.25 235 16.53 420
K10 CONIC, K10 CONIC PB 25 655 9.25 235 16.53 420
K10 MASTER CONIC,
K10 MASTER CONIC PB
27.55 700 9.25 235 16.53 420
in mm in mm in mm
7.4. Grinder Installation
Before grinder installation, the following should be considered:
• The grinder information plaque data coincides with the electrical system on
site.
• The electrical outlet coincides with the grinder plug.
• The electric power at the location of installation should meet the minimum
required to properly run the grinder.
• The installation site should have the proper electrical overload protections.
• The grinder should be properly grounded as specied by local code.
NOTE: The grinder should be used in environments with mínimum temperature
of 77-86F and should not be installed in places (such as industrial kitchens) where
cleaning is done with direct water spray cleaning.
