ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 02/09/2016 | K01068

8. REGULATION

8.1. Grinder set up

Place the hopper ( ) on the grind regulator ( ) and make sure the bean trap ( )

is in the closed position. Lock the hopper ( ) in place using a at head screw driver

to gently tighten the hopper security screw making it match to the hole at the bean

hopper collar ( ) (Fig. 1).

Remove the hopper lid ( ), ll the hopper with coffee ( ), and replace the lid on the

hopper ( ) (Fig. 2).

Plug in the grinder, and place the main power switch ( ) ON-OFF to position ON and

open the bean trap ( ) to allow coffee to pass into the grind chamber.
