![Compak К6 [4/26] Description](/views2/1335834/page4/bg4.png)
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 02/09/2016 | K01068
2
SOUND DECIBEL LEVEL
The level of sound emitted in different models is:
Sound decibel level With coffee
K3, K3 ELITE 75,3 dB
K6, K6 PB 73,2 dB
K6 SILENZIO 68,7 dB
K8 SILENZIO 70,2 dB
K10 CONIC, K10 CONIC PB 68,4 dB
K10 MASTER CONIC, K10 MASTER CONIC PB 67,8 dB
2. DESCRIPTION
Your new grinder has been designed using the most sophisticated technologies in
existence. The result is a product of high quality that offers the assurance of the best
results possible. Our products are manufactured by hand, one by one, following the
strictest quality requirements. In the manufacturing process, we use only the highest
quality materials (aluminum, stainless steel, etc.) especially designated for being in
contact with food stuff.
For the optimum functionality of the grinder models described in this user manual,
the maximum work cycles are as follows:
Model
Working cycle
ON OFF
K3, K3 ELITE 2 minutes 10 minutes
K6, K6 SILENZIO, K6 PB 5 minutes 10 minutes
K8 SILENZIO, K10 CONIC, K10 CONIC PB 2 minutes 10 minutes
K10 MASTER CONIC, K10 MASTER CONIC PB 2 minutes 10 minutes
