E n g l i s h | 10
If the problem persists we advise you to consult a retailer of the manufacturer for Assistance
Service specifying the problem and supplying your the code (Art.) and appliance Ser N°. This
information is provided on the INFORMATION PLATE on the back of the machine.
SPARE PARTS
Use only authorized parts for product repair. All interventions shall be carried out by authorized and
specialized technical personnel. Contact the Assistance Centre to request spare parts.
VI. ADVICE DURING COOKING
Where the grill is used to cook fatty food such as roasts or poultry it is advisable to insert a
container on the bottom of the cooking chamber to collect the fat during cooking.
While cooking food with full containers or filled with liquids, ensure
they do not spill, both during and after cooking on taking them out of
the oven. Scalding danger!
When ovens are placed on proving cabinets, stainless steel tables or
other ovens, it is not advisable to use shelves so high that the inside of
the oven is not at eye level. Scalding danger!
Always clean accessories before use.
To cook food perfectly and uniformly it is not advised to use deep baking trays because they would
prevent the correct air circulation. There must be a space of at least 2cm between the top tray and
food.
To cook uniformly do not overload the oven and make sure baked goods or bread face the right
direction toward airflow in the cooking chamber.
FAILURE CAUSE SOLUTION
Oven light OFF
Loose lamp Correctly fit the lamp into the lamp holder
Blown lamp Replace the lamp (see ordinary maintenance )
Non-uniform cooking
by the chamber
The fan is not operating
Contact specialized technician for repair
(Assistance Service ).
Failure of the heating
element
Contact specialized technician for repair
(Assistance Service ).
The oven is
completely OFF
Supply voltage failure Restore power supply voltage
Incorrect connection to
the power supply
network
Check connection to the power supply network
Thermal cut-out
disconnected the
power supply
Wait until the oven temperature goes below the
safety threshold and contact the specialized
technician for repair (Assistance Service).
Water leaking from the
gaskets with the door
closed
Dirty gasket Clean the gasket with a damp cloth
Damaged gasket
Contact specialized technician for repair
(Assistance Service).
Problem regarding the
closure of the door
Contact specialized technician for repair
(Assistance Service).
