PIRON PF5504 [6/13] E n g l i s h 5

E n g l i s h | 5

INFORMATION

POWER

CONSUMPTION

SUPPLY

FREQUENCY

VI. DRAINAGE CONNECTION

FUMES DISCHARGE

Hot fumes and odors are emitted from the cooking chamber during cooking. This is located at the

top back of the oven. Do not place objects on the discharge so as not to hinder the outflow of the

fumes and hence avoid causing damage thereto. It is advisable to position the oven under a

suctioning or ensure adequate ventilation to the outside for hot fumes and odors through a pipe no

smaller than the oven exhaust. Avoid bends and blockages.

VII. SPECIFICATIONS

Manufacturer: Piron S.r.l.

Address: Via Belladoro, 25 – 35010 Cadoneghe (PD) - Italy

Product: Convection oven.

Class : 1

INFORMATION PLATE
