PIRON PF5504 [13/13] Vii mechanical oven control panel

E n g l i s h | 12

Timer knob

Thermostat knob

Thermostat light

VII. MECHANICAL OVEN CONTROL PANEL

• TIMER KNOB

When manual is selected, the oven stays on until someone turns it off.

When a certain value is selected, the oven stays on for that time (120 minutes maximum).

• THERMOSTAT KNOB

This knob allows selecting the desired coking temperature.

• THERMOSTAT LIGHT

This light is on when the oven heating elements are on therefore the temperature in the

cooking chamber is less than that set by the thermostat dial. When the light goes off it means

that the heat is off and that the cooking chamber has reached the set temperature.
