E n g l i s h | 6
INSTRUCTIONS FOR THE USER
I. WARNING
Read this instructions booklet carefully in that it provides indications regarding safety and
use of the appliance.
Store carefully for reference at all times.
Incorrect installation, assistance, maintenance, cleaning, tampering or modifications can
cause malfunction, damage and breakage.
The oven must only be used for foods in industrial and professional kitchens. Any other use is
inappropriate. This appliance is intended for professional use only.
The producer shall be deemed relieved from any liability arising from uses different from the ones
indicated.
The appliance is intended for professional use only and it shall be used by qualified personnel.
• The appliance is not suitable for use by people with low physical or mental abilities or lacking
experience, unless instructed regarding the operation of the oven by the personnel in charge of
their safety.
• Do not leave the appliance unattended in presence of children and ensure that the latter do not
have access to the appliance.
• It is thus strongly recommended not to position sources of heat near the apparatus.
• Do not under any circumstance, leave flammable material near a appliance: it can be a fire
hazard.
• Food container temperatures, accessories or other objects can be very hot; beware of burns
when moving them. Only touch them with relevant thermal protection.
• While opening the oven door: there is danger of scalding due to high temperature emissions.
• Use protective gloves or other personal protection equipment in case of spilling hot food stuff.
• Do not put flammable or alcohol based foods in the oven as they can cause combustion and
explosions.
• Avoid putting salt on food inside the cooking chamber of the oven. If this cannot be avoided,
ensure that it is cleaned as soon as possible as it can cause damage to the cooking chamber.
• Warning: the floor near the appliance may be slippery.
• The maximum weight for tray must not exceed 2,5 Kg.
The outside parts of the oven can exceed a
temperature of 60°C, therefore in order to
avoid burning it is advised not to touch the
external parts marked by the symbol shown
here.
Damage or breakage of door glass components must be substituted immediately (contact
the Assistance Centre).
If it is not in use for long periods of time (many days) it is advisable to turn it off at the main.
The producer shall not be deemed liable for any damage incurred by persons or properties,
caused by non compliance with the aforementioned instructions of deriving from tampering
with even a single part of the appliance and use of non-genuine spare parts.
