-21-
8. Insulation Tests
Upon completing reassembly after repair, measure the insulation resistance and conduct a dielectric
strength test.
Insulation resistance: 7 M ȳ or more using a 500 VAC megohm tester
Dielectric strength: AC 4,000 VAC/minute, with no abnormalities 220 V to 240 V (110 V for UK products)
AC 2,500 VAC/minute, with no abnormalities 110 V to 127 V (except UK products)
9. No-Load Current Value
After no-load operation for 30 minutes, the no-load current values should be as follows:
[DV 13SS, DV 13VSS]
Voltage (V) 110 120 220 230 240
Current (A) Max. 2.9 2.7 1.5 1.4 1.3
[DV 16SS, DV 16VSS]
Voltage (V) 110 120 220 230 240
Current (A) Max. 3.0 2.8 1.5 1.4 1.3
