-2-
Efficient operation thanks to the high-power motor
(Models DV 13SS/DV 13VSS: 550 W (0.74 HP),
Models DV 16SS/DV 16VSS: 600 W (0.81 HP))
The Models DV 13SS, DV 13VSS, DV 16SS and DV 16VSS are equipped with a high-power motor (550
W/600 W) to generate sufficiently high torque to cope with heavy-load operations such as drilling into metal
and wood materials. These models can be operated efficiently without reducing torque thanks to the high-
power motor.
(Reference)
HITACHI
HITACHI
Model
DV 13SS
DV 13VSS
DV 16SS
DV 16VSS
C1 C2 B1 B2
FDV 16VB2 DV 16V
Input
W
(HP)
550
(0.74)
600
(0.81)
430
(0.58)
710
(0.95)
600
(0.81)
701
(0.94)
550
(0.74)
590
(0.80)
Maximum
torque
N•m
(in•lbs)
12.4
(110)
15.4
(136)
7.7
(68)
13.4
(119)
10.8
(96)
–
(–)
9.6
(85)
12.6
(112)
Available for various applications thanks to the variable speed
control switch with the forward/reverse changeover switch
(Models DV 13VSS and DV 16VSS only)
The Models DV 13VSS and DV 16VSS are equipped with a variable speed control switch with a
forward/reverse changeover switch so that the direction of rotation and speed can be freely adjusted
according to specific applications and materials.
Durable cylindrical housing
The Models DV 13SS, DV 13VSS, DV 16SS and DV 16VSS offer significantly improved durability thanks to
the adoption of a durable cylindrical housing.
(Reference)
HITACHI
HITACHI
Model
DV 13SS/DV13 VSS
DV 16SS/DV16 VSS
C1
C2
B1
B2
FDV 16VB2 DV 16V
Housing
structure
Cylindrical
(without elastomer)
Cylindrical
(without elastomer)
Clamshell
(with elastomer)
Clamshell
(with elastomer)
Cylindrical
(with elastomer)
