-6-
[16 mm class] (Superior specifications: )
(Reference)
HITACHI
Maker • Model
Item
HITACHI
DV 16SS
DV 16VSS
C2 B2
FDV 16VB2 DV 16V
Concrete
mm
(in.)
16 (5/8”) 16 (5/8”) 16 (5/8”) 16 (5/8”) 16 (5/8”)
Steel
mm
(in.)
13 (1/2”) 13 (1/2”) 13 (1/2”) 13 (1/2”) 13 (1/2”)
Capacities
Wood
mm
(in.)
25 (1”) 30 (1-3/16”) 30 (1-3/16”) 25 (1”) 25 (1”)
Drill chuck capacity
mm
(in.)
1.5 to 13
(1/16 to 1/2”)
1.5 to 13
(1/16 to 1/2”)
1.5 to 13
(1/16 to 1/2”)
1.5 to 13
(1/16 to 1/2”)
1.5 to 13
(1/16 to 1/2”)
Power input
W
(HP)
600 (0.81) 710 (0.95) 701 (0.94) 550 (0.74) 590 (0.80)
No-load speed /min.
DV 16SS: 2,900
DV 16VSS:
0 to 2,900
0 to 3,000 0 to 2,600 0 to 2,900 0 to 2,900
No-load impact rate /min.
DV 16SS: 46,400
DV 16VSS:
0 to 46,400
0 to 45,000 0 to 41,600 0 to 46,400 0 to 46,400
Weight
kg
(lbs.)
1.5* (3.3) 2.0** (4.4) 1.9** (4.2) 1.6** (3.5) 1.5* (3.3)
No-load speed /min.
2,682 3,112 2,600 2,845 3,317
No-load noise level dB
81.4 – – 77.1 82.0
No-load vibration
level
m/s
2
1.3––1.31.0
Actual noise level dB
91.8 – – 93.4 93.1
Actual vibration
level
m/s
2
7.1 – – 11.2 10.0
Maximum torque
N•m
(In•lbs)
15.4 (136) 13.4 (119) – (–) 9.6 (85) 12.6 (112)
Overall
length
mm
(in.)
270 (10-19/32”)
297 (11-23/32”) 295 (11-39/64”)
288 (11-5/16”) 269 (10-39/64”)
Width
mm
(in.)
67 (2-5/8”) 71 (2-13/16”) 70 (2-49/64”) 67 (2-41/64”) 63 (2-31/64”)
Overall
height
mm
(in.)
186 (7-5/16”) 194 (7-41/64”) 203 (8”) 199 (7-53/64”) 181 (7-1/8”)
Dimensions
Center
height
mm
(in.)
28.2(1-7/64”) 28.0 (1-7/64”) 310 (12-13/64”) 27.5 (1-5/64”) 27.0 (1-1/16”)
Weight
kg
(lbs.)
1.7** (3.7)
2.1** (4.6) 1.9** (4.2) 1.7** (3.7) 1.7** (3.7)
Housing structure
Cylindrical Cylindrical Clamshell Clamshell Cylindrical
Gear cover material
Resin Resin – – Aluminum
Inner cover (holder) material
Resin
Aluminum
(holder)
Aluminum
(holder)
Aluminum
(holder)
Aluminum
Forward/reverse changeover
switch
DV 16SS:
Not provided
DV 16VSS:
Provided
Provided Provided Provided Provided
Switch fine adjustment dial
Not provided Not provided Provided Provided Provided
Soft grip
Not provided Not provided Provided Provided Provided
* : Excluding the drill chuck, cord, side handle and depth gauge
**: Excluding the cord, side handle and depth gauge
Listed value
Measured value
