-3-
1. Specifications
Product name 13 mm impact drill 16 mm impact drill
Model DV 13SS DV 13VSS DV 16SS DV 16VSS
Concrete 13 mm (1/2”) 16 mm (5/8”)
Steel 13 mm (1/2”) 13 mm (1/2”)
Capacities
Wood 20 mm (3/4”) 25 mm (1”)
Mount type 1/2”-20UNF
Drill chuck
Capacity 1.5 to 13 mm (1/16” to 1/2”)
Frequency AC single phase 50/60 Hz
Power
source
Voltage 110V, 120V, 220V, 230V, 240V
Type of motor AC single-phase series commutator motor
Enclosure
Glassfiber reinforced polyamide resin ---------- Housing, handle cover,
gear cover and inner cover
Types of switches
DV 13SS,DV 16SS: ON-OFF trigger switch
DV 13VSS,DV 16VSS: Variable speed control switch with forward/reverse
changeover switch
Full-load current
110V:5.4A,
120V:4.9A
220V:2.7A,
230V:2.6A,
240V:2.5A
110V:5.9A,
120V:5.4A
220V:2.9A,
230V:2.8A,
240V:2.7A
Power input 550W (0.74HP) 600W (0.81HP)
No load 2,900/min. 0 to 2,900/min. 2,900/min. 0 to 2,900/min.
Speed
Full load 1,990/min. 1,940/min.
No load 46,400/min.
0 to 46,400/min.
46,400/min.
0 to 46,400/min.
Impact
rate
Full load 31,840/min. 31,040/min.
Full-load output 260 W (0.35HP) 315 W (0.42HP)
Maximum output 545 W (0.73HP) 690 W (0.93HP)
Maximum torque 12.4 N•m (110 in•lbs) 15.4 N•m (136 in•lbs)
Listed value*
1
1.4 kg (3.1lbs.) 1.5 kg (3.3lbs.)
Weight
Measured
value*
2
1.6 kg (3.5lbs.) 1.7 kg (3.7lbs.)
Overall
length x width x overall height
270 x 67 x 186 mm
(10-19/32 x 2-5/8 x 7-5/16”)
Specification for
keyed chuck
•Chuck handle ---- 1
Specification for
keyed chuck
•Chuck handle ----1
• Side handle ------1
• Depth gauge -----1
Standard accessories*
3
Specification for
keyed chuck
•Chuck handle ----1
Specification for
keyless chuck
• Side handle ----- 1
• Depth gauge ---- 1
• Case --------------- 1
Specification for
keyed chuck
•Chuck handle ---- 1
• Side handle ----- 1
• Depth gauge ---- 1
Specification for
keyless chuck
• Side handle ------1
• Depth gauge -----1
• Case ---------------1
*
1
: Excluding the drill chuck, cord, side handle and depth gauge
*
2
: Excluding the cord, side handle and depth gauge
*
3
: Standard accessories may vary depending on the market areas.
