Hotpoint-Ariston C 34S N1 R/HA [19/36] Start up and use

Using the hob

Lighting the burners

For each BURNER knob there is a complete ring

showing the strength of the flame for the relevant

burner.

To light one of the burners on the hob:

1. Bring a flame or gas lighter close to the burner.

2. Press the BURNER knob and turn it in an

anticlockwise direction so that it is pointing to the

maximum flame setting -.

3. Adjust the intensity of the flame to the desired

level by turning the BURNER knob in an

anticlockwise direction. This may be the minimum

setting +, the maximum setting - or any position in

between the two.

If the appliance is fitted with

an electronic lighting device*

(see figure), press the ignition

button, marked with the

symbol XXX, then hold the

BURNER knob down and turn

it in an anticlockwise direction,

towards the maximum flame

setting, until the burner is lit. The burner may be

extinguished when the knob is released. If this

occurs, repeat the operation, holding the knob down

for a longer period of time.

 If the flame is accidentally extinguished, switch off

the burner and wait for at least 1 minute before

attempting to relight it.

If the appliance is equipped with a flame failure

safety device*, press and hold the BURNER knob for

approximately 2-3 seconds to keep the flame alight

and to activate the device.

To switch the burner off, turn the knob until it reaches

the stop position .

Practical advice on

using the burners

For the burners to work in the most efficient way

possible and to save on the amount of gas

consumed, it is recommended that only pans that

have a lid and a flat base are used. They should also

be suited to the size of the burner.

To identify the type of burner, please refer to the

diagrams contained in the Burner and nozzle

specifications.

Start-up and use

Using the oven

 The first time y ou use your appliance, heat the

empty oven with its door closed at its maximum

temperature for at least half an hour. Ensure that the

room is well ventilated before switching the oven off

and opening the oven door. The appliance may emit

a slightly unpleasant odour caused by protective

substances used during the manufacturing process

burning away.

 Before operating the product, remove all plastic film

from the sides of the appliance.

1. Select the desired cooking mode by turning the

SELECTOR knob.

2. Select the recommended temperature for the

cooking mode or the desired temperature by turning

the THERMOSTAT knob.

A list detailing cooking modes and suggested

cooking temperatures can be found in the relevant

table (see Oven cooking advice table).

During cooking it is always possible to:

 Change the cooking mode by turning the

SELECTOR knob.

 Change the temperature by turning the

THERMOSTAT knob.

 Set the total cooking time and the cooking end

time (see below).

 Stop cooking by turning the SELECTOR knob to

the 0 position.

 Never put objects directly on the bottom of the

oven; this will avoid the enamel coating being

damaged. Only use position 1 in the oven when

cooking with the rotisserie spit.

 Always place cookware on the rack(s) provided.

Only available in certain models.

Burner ø Cookware diameter (cm)

Fast (R) 24 - 26

Semi Fast (S) 16 - 20

Auxiliary (A) 10 - 14
