10
Switching o:
• Press and release the switch button (8).
ADJUSTMENT OF SANDING BELT POSITION SETTING THE
GUIDE ROLLERS PARALLEL
• Switch the sander on.
• During sanding belt movement turn the sanding belt adjustment
wheel (5) (g. F) so the sanding belt runs smoothly and does not
move aside (g. G).
If you allow the sanding belt to shift to the side (which would
mean that roller axes are not parallel), the belt will be damaged
soon.
When using the belt sander try to position the belt surface and
surface of processed material in parallel. Hold the additional grip
(1) and main handle (7) firmly and move the sander back and forth
smoothly.
Do not press the belt sander too hard. Pressure must be moderate
and uniform on the whole surface of contact of belt and processed
material. Applying too big pressure causes undesirable drop of
belt speed, motor overheating, damage of processed material and
parts of the sander. Make periodic breaks in operation.
COVER OF SANDING BELT
When lifted, the removable sanding belt cover (14) allows to process
with front upper part of the sanding belt, which facilitates operation
in hardly accessible places (g. K).
OPERATION AND MAINTENANCE
Remove the power cord plug from mains socket before
commencing any activities related to installation, adjustment,
maintenance or repair of power tool.
• Always keep the sander and ventilation holes clean.
• Use brush to remove sanding dust.
• Clean the belt sander regularly, optimally after each use.
• Do not use abrasive objects for cleaning the sander.
• Use soft cloth for cleaning the body.
• For cleaning never use petrol, solvents or detergents that could
damage plastic parts of the sander.
• When the work is finished empty the dust bag, wash it in warm
water with soap and dry it thoroughly.
REPLACEMENT OF DRIVING BELT
Belt sander will not work properly if driving belt is worn. Belt
replacement is necessary.
• Use screwdriver to unscrew fixing screw of driving belt cover (4)
and remove the cover.
• Remove the driving belt by turning the wheels manually and
pulling the belt off.
• To install new driving belt do as follows:
- put the belt onto bigger drive wheel,
- rotate wheels to draw the driving belt over smaller drive wheel.
• Install driving belt cover (4) and tighten fixing screw.
Ensure the driving belt is correctly set on both drive wheels.
CHECKING SANDING BELT
Due to loss in efficiency after long time of using the same sanding
belt, replace the belt immediately when you see it is excessively
worn.
REPLACEMENT OF CARBON BRUSHES
Replace immediately used up (shorter than 5 mm), burnt or cracked
motor carbon brushes. Always replace both brushes at a time.
• Unscrew brush covers (2) (g. H).
• Remove used brushes.
• Remove any carbon dust with compressed air.
• Insert new carbon brushes (brushes should easily move into
brush-holders).
• Install brush covers (2).
After the brushes are replaced start the sander with no load
and wait until the brushes t to the motor commutator. Entrust
replacement of carbon brushes only to a qualied person. Only
original parts should be used.
All faults should be repaired by service workshop authorized by the
manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Belt sander
Parameter Value
Supply voltage 230 V AC
Current frequency 50 Hz
Rated power 800 W
Range of sanding belt speed
without load
260 m/min
Active sanding surface 75 x 146 mm
Size of sanding belt 75 x 457 mm
Protection class II
Weight 3,1 kg
Year of production 2016
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure: Lp
A
= 90,4 dB(A) K = 3 dB(A)
Sound power: Lw
A
= 101,4 dB(A) K = 3 dB(A)
Weighted value of vibration acceleration: a
h
= 5,244 m/s
2
K = 1,5 m/s
2
ENVIRONMENTAL PROTECTION / CE
Electrical equipment must not be disposed off with household
waste and, instead, should be utilized at appropriate facilities.
Information on utilization can be provided by the product
vendor or the local authorities. Waste electrical and electronic
equipment contains substances that are not neutral to
the natural environment. Equipment that is not recycled
constitutes a potential hazard to the environment and to
human health.
* Right to introduce changes is reserved.
“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka komandytowa with seat in Warsaw at
ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all copyrights to this instruction (hereinafter
Instruction), including, but not limited to, text, photographies, schemes, drawings and layout of the
instruction, belong to Grupa Topex exclusively and are protected by laws accordingly to Copyright
and Related Rights Act of 4 February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U.
2006 No 90 item 631 with later ammendments). Copying, processing, publishing, modifications for
commercial purposes of the entire Instruction or its parts without written permission of Grupa Topex
are strictly forbidden and may cause civil and legal liability.
ÜBERSETZUNG DER
ORIGINALBETRIEBSANLEITUNG
BANDSCHLEIFMASCHINE
59G392
ACHTUNG: LESEN SIE VOR DER INBETRIEBNAHME DIESES
ELEKTROWERZEUGS GRÜNDLICH DIE VORLIEGENDE
BETRIEBSANLEITUNG DURCH UND BEWAHREN SIE SIE AUF.
DETAILLIERTE SICHERHEITSVORSCHRIFTEN
• Die Bandschleifmaschine darf nur zum Schleifen verwendet
werden.
• Verwenden Sie die Bandschleifmaschine nie im stationären
Betrieb.
• Die Einatmung des Staubs von Bleifarben, manchen Holzarten,
z.B. Eichenholz, Metallstaub ist gesundheitsschädlich. Aus
diesem Grund ist die Schleifmaschine grundsätzlich mit einer
Staubvorrichtung zu betreiben
.
• Mit der Schleifmaschine dürfen keine asbesthaltigen Stoffe
bearbeitet werden.
