Descriptions of used pictograms.
1 2 3 4
5 6 7 8
1. Warning, take special precautions.
2. Read the instruction manual, observe warnings and safety
conditions included in it!
3. Use personal protection equipment (safety goggles, ear
protectors).
4. Use safety gloves.
5. Disconnect the power cord, before maintenance or repair
works are begun.
6. Keep out of reach of children.
7. Protect against rain
8. Protection class II
DESIGN AND APPLICATION
The angle grinder is a hand-held power tool with the II
class isolation. The power tool is driven with a single-phase,
commutator motor, whose rotational speed is reduced by means
of an intersecting axis gear. The power tool can used both for
grinding and cutting. This type of power tools is widely used for
removal of burrs from metal surfaces, weld surface processing,
cutting light-wall tubes and other small metal objects etc. They
are used in engineering industry, automotive and chemical
industry. With the use of proper tools, the angle grinder can be
used not only for cutting or grinding, but also for rust and paint
coats removal.
The areas of its application include repair and construction
works, not only related to metals. The angle grinder can also be
used for cutting and grinding of construction materials, such as
brick, paving stones, ceramic tiles, etc.
The power tool is designed for dry operation only and it must
not be used for polishing. The power tool should be used
according to its purpose.
Use inconsistent with its purpose
• Do not work materials that contain asbestos. Asbestos is
carcinogenic.
• Do not work materials, whose dust is inflammable or
explosive. During operation, the power tool produces sparks,
which may ignite emitted vapours.
• Do not use cut-off wheels for grinding. The cut-off wheels
are used to cut with its face, while grinding with lateral surface
of such a cut-off wheel threatens with its damages and puts the
operate in danger of injuries.
DESCRIPTION OF GRAPHIC PAGES
The below list refers to device components shown in the graphic
pages of this instruction manual.
1. Spindle lock button
2. Switch
3. Additional handle
4. Grinding wheel cover
5. External flange
6. Internal flange
7. Switch lock button
8. Carbon brush cover
9. Main handle lock
10. Lever (grinding disc guard)
11. Speed control dial
* There can be differences between the drawing and actual product.
Specific safety guidelines for working with wire brushes
• It should always be remembered that pieces of wire are
lost even during normal use. Do not overload wires by
putting excessive pressure. Airborne pieces of wire may easily
puncture thin clothing and/or skin.
• If a guard is recommended to be used, prevent a brush
from touching the guard. A brush diameter for plates and pots
may increase due to the pressure and centrifugal forces.
Additional safety guidelines
• Before connecting to the power source, always make sure
the supply voltage is compatible with the value specified
on the nameplate of the tool.
• Before the grinder is connected, always check the power
cord. In case of damage, have it repaired in an authorised
workshop.
• Before all installation works, the plug should be taken out
of the receptacle.
• Grinding tools should be checked before each use. A
grinding tool must be correctly fastened and should rotate
freely. As part of the test, the tool should be switched on
with no load for at least one minute in a safe position. Do
not use damaged or vibrating grinding tools. Grinding
tools should be round. Damaged grinding tools may break
and cause injuries.
• Once a grinding tool is installed and before the grinder
is switched on, check the grinding tool for correct
installation and free rotations, and whether it does not
catch the guard.
• The spindle lock button can be activated, only when the
grinder spindle does not move.
• In case of tools adapted for fastening of grinding wheels
with a threaded opening, make sure the grinding wheel
thread length is suitable for the spindle thread length.
• Always secure the workpiece. It is always preferable to
secure the workpiece in a vice or other fastening tool than
holding it in your hand.
• If own weight of the workpiece does not guarantee a stable
position, it should be fastened.
• Do not touch cut-off and grinding wheels, before they cool
down.
• Do not exert lateral pressure on the grinding or cut-off
wheel.
• Do not cut a workpiece of a thickness larger than the
maximum cutting depth of the cut-off wheel.
• When quick release flange is used, make sure that inner
flange seated on the spindle is equipped with rubber
O-ring and this ring is not damaged. Also surfaces of the
outer flange and the inner flange must be clean.
• Use quick release flange only with cutting and grinding
discs. Use only flanges that are free from defects, that
operate correctly.
• In case of temporary mains power failure or after
disconnecting plug from mains socket with the switch in
ON position, unlock the switch and set it to OFF position
before starting the tool again.
NOTE: The tools is intended for indoor works.
Despite using the construction, which is safe by design itself,
protection means and additional safety features, there is
always a residual risk of injuries during operation.
