38 GW27-013_v01
6
After nishing toasting cycle, the toasting lever (5) shall
lift up automatically.
Remove the toast carefully, not to touch any hot surface.
In a very rare case, when the bread is blocked inside the
toaster, switch off the power and unplug the appliance. Let
the toaster cool down before you loose the bread carefully
not to damage heating elements.
Defrosting function
Insert the frozen bread inside bread inlets
●
(4).
Select desired toasting settings as mentioned above.
●
Press the toasting lever
●
(5) down, to move down the bread.
When the bread is inside the toaster, press defrosting
●
button (a). The button shall be highlighted.
Toasts re- heating function
This toaster provides the feature of toasts re- heating without
additional toasting. In order to re- heat:
Place the toasts in bread inlets
●
(4).
Press the toasting lever
●
(5) down, to insert the bread
inside the toaster.
When the bread is down, press re- heating button
●
(b).
The button shall be highlighted.
Cancel button
In order to cancel the toaster operation, re-heating or defrosting,
press the cancel button (c) in any moment of toasting cycle.
The toasting lever (5) shall lift up to the top position.
Additional lift- up function
In order to remove the bread after toasting cycle, the toasting
lever (5) allows lifting toast up, above initial level.
Single slice toasting
In case you want to toast a single slice, adjust the lower
setting than usual. The toaster is prepared such way, that it
toasts the bread in both bread inlets. When you reduce the
toasting power for one slice, it will not get burned. When you
realize, that the toast is ready, use the cancel button (c).
Tips on toasting
Toasting is a combination of roasting and drying. The
humidity levels are different for various kinds of bread, which
can result in different time of toasting.
Use lower setting than usual, for a bit dry bread.
●
Use higher setting than usual for fresh or wheat bread.
●
The bread of a very rough surface can require higher
●
setting.
Toasting of thicker slices require longer, sometimes
●
much longer time, due to bigger amount of humidity to be
removed from bread. Very thick slice require two toasting
cycles sometimes.
When you toast the bread with raisins or other fruits,
●
remove lousy raisins from the surface before inserting it
into the toaster. It will prevent separating these particles
inside the toaster or sticking it to the wire screen inside
the inlet.
Technical parameters
The toaster technical parameters are included at the name
plate. The toaster is I class appliance, equipped with
supplying cord and plug with grounding.
ZELMER toaster meets the requirements of effective
standards.
This device complies with Commission Regulation (EC)
no. 1275/2008 on eco-design requirements.
The appliance meets the requirements of the following
directives:
Low voltage appliance (LVD) – 2006/95/EC. –
Electromagnetic compatibility (EMC) – 2004/108/EC. –
The appliance was marked by the CE sign on the rating label.
Outline (Fig. A)
1
Control panel
a
Defrost button
b
Re - heating button
c
Cancel button
d
Control lights (type 27Z013 inox – horizontal control
lamps)
2
Temperature dial knob
3
Removable crumbs tray
4
Adjustable bread inlets
5
Toasting lever/lift-up lever
6
Cord rewind compartment (at the bottom)
Toaster handling and operation (Fig. B)
1
Place the toaster on dry, stable surface, far from the heat
sources (heating boards, cookers, oven, i.e.).
2
Insert the plug into mains supply outlet.
3
Insert two slices of bread into both bread inlets (4).
4
Select desired toasting time with time dial knob (2).
Move the time dial left to reduce toasting time.
●
Move time dial right to increase toasting time.
●
The time setting range is scaled from position 1 (light)
●
to 6 (strong).
5
In order to insert the bread into the toaster, press
the toasting lever (5) down, up to the moment it is locked
The cancel button shall be highlighted (c) and the toasting
process shall start.
All ve control lights shall glow
●
(d). During toasting cycle
shall go off step by step, up to the last one when toasting
is nished.
The toasting cycle can be stopped in any moment
●
pressing cancel button (c).
In order to make easier removing smaller items like cookies
●
or mufns, lift the lever (5), up as much as possible.
In case the bread is not enough brown, you can Re-toast
●
it. Select light toasting (the knob in position 1-2) press
the toasting lever (5) down. Pay attention to the toaster,
to avoid burning the toast.
