Page 25
Technical data
MQL 10M 10T 12 15 17
Power supply
V/ph/Hz
220V-1-50Hz 400/3+N/50 400/3+N/50 400/3+N/50 400/3+N/50
Number of circuits 11111
Number of steps
0-100 0-100 0-100 0-100 0-100
Refrigerant
Type R407C
Charge (1) kg 2.42 2.42 2.43 3.6. 3
Compressors
Type Scroll Scroll Scroll Scroll Scroll
Number 11111
Start-up type Direct
Evaporator
Type Slabs
Number 11111
Condenser
Type Battery (Al/Cu)
Hydraulic connections
Type Female
Inlet diameter inch 1” 1” 1” 1” 1”
Outlet diameter inch 1” 1” 1” 1” 1”
Weights
Weight of shipment kg 153 153 158 160 166
Dimensions
Length mm 1182 1182 1182 1182 1182
Width mm 400 400 400 400 400
Height mm 1309 1309 1309 1309 1309
(1) Indicative value. Always refer to the value specified on the unit’s label.
English
Manuale MQL-MQH 10.6.2005 12:26 Pagina 25
