Airwell MQL 6 [32/40] English
![Airwell MQH 8Т [32/40] English](/views2/1409105/page32/bg20.png)
Page 31
English
Technical data
8.4 Clearences
MQL/MQH 4-8
200 mm
500 mm
800 mm
800 mm
400 mm
MQL/MQH 10-17
200 mm
500 mm
800 mm
800 mm
400 mm
Manuale MQL-MQH 10.6.2005 12:26 Pagina 31
