Electrical Data Compressors
Technical data
8.2 Unit Electrical Data
MQL/MQH 4 6 8M 8T
Rated voltage V/ph/Hz 230V-1-50Hz 400/3+N/50
Max. absorbed power kW 2.2 2.7 4.6 4.6
Rated current A 8.3 10.1 16.4 7.5
Max. current (FLA) A 9.7 11.7 20.7 8.6
Max. start-up current (LRA) A 38 53 77 37
External fuses (A) 16 16 25 16
Max. cable section (1) mm
2
2.5 2.5 4.0 2.5
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working tempera-
ture in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
n.d. Not available.
MQL/MQH 10M 10T 12 15 17
Rated voltage V/ph/Hz 230V-1-50Hz 400/3+N/50
Max. absorbed power kW 5.6 5.4 6.3 7.3 8.3
Rated current A 19.7 9.6 11.2 11.7 13.5
Max. current (FLA) A 26.4 11.4 13 14.7 16.9
Max. start-up current (LRA) A 115 51 67 75 102
External fuses (A) n.d. n.d. n.d. n.d. n.d.
Max. cable section (1) mm
2
n.d. n.d. n.d. n.d. n.d.
Compressors MQL/MQH 4 6 8M 8T
Number n° 1111
Max. absorbed power kW 1,8 2,3 4,2 4,2
Nominal current A 6,6 8,4 14,7 5,8
Max. current (FLA) A 8 10 19 6,9
Max. start-up current (LRA) A 37 52 76 36
Oil pan resistor W – – 70 70
Compressors
MQL/MQH 10M 10T 12 15 17
Number n° 11111
Max. absorbed power kW 4,9 4,7 5,6 6,6 7,6
Nominal current A 16,3 6,2 7,8 8,3 10,1
Max. current (FLA) A 23 8 9,6 11,3 14
Max. start-up current (LRA) A 114 50 66 74 101
Oil pan resistor W 70 70 70 70 70
